4
Technical characteristics
GENERAL DATA
Product height (mm) 190
Product width (mm) 103
Product depth (mm) 28
Product weight (g) 300
Product colour White RAL9003
Material ABS
Surface-mounted Yes
Desk base-mounted Yes, with specific accessory
COMPATIBLE SYSTEMS
Simplebus1 audio Yes
AUDIO SPECIFICATIONS
Microphone 9.6 (ø) x 6.9mm, omnidirectional
Loudspeaker 50 mm (Ø), 50 Ohm, 0.25W
Technologies implemented Full-Duplex
ELECTRICAL SPECIFICATIONS
Type of power supply Power supply via video entry bus
Power supply voltage 22 - 28 VDC
Maximum absorption (W) 0.6
HARDWARE CHARACTERISTICS
Type of buttons Mechanical
Service buttons Lock-release
Terminals L L CFP CFP
Number of inputs (no.) 1
SETTINGS
Ringtone volume Yes
ENVIRONMENTAL AND CONFORMITY SPECIFICATIONS
Operating temperature (°C) -5 to 40
Operating humidity (max RH - %) 25 to 75
Environmental class III
Conformity and Certifications RoHS II - 2011/65/EU (EN 50581:2012), EMC 2014/30/EU
(EN 61000-6-1:2007, EN 61000-6-3:2007+A1:2011)
MAIN FUNCTIONS
Lock-release Yes
Actuator control Yes
Switchboard call Yes
Input for floor door call Yes
Silent mode (Privacy) Yes
Call repetition Yes, with additional board art. 2735 (not included)
