Comelit MT VCC 01 - Diva Audio Unit Art. 4781 with Bracket Art. 4786 Installation; Italian Installation Instructions; English Installation Instructions; French Installation Instructions

GROUP S.P.A.
MT VCC 01
24
1
Misure di ingombro del Monitor.
Monitor dimensions.
Dimensions d'encombrement du moniteur.
I
GB
F
145 cm
63 mm
2
Installazione monitor Art. 4781 su scatola da incasso. La scatola serie civile 503 (Art. 4517) deve essere murata in posizione verticale.
Installing a wall-mounted monitor Art. 4781 on a housing box. The civil series 503 box (Art. 4517) must be embedded in the wall in a vertical position.
Installation du moniteur Art. 4781 sur boîtier à encastrer. Le boîtier série civile 503 (Art. 4517) doit être monté au mur en position verticale.
I
GB
F
ISTRUZIONI PER INSTALLAZIONE POSTO INTERNO DIVA
AUDIO ART. 4781 SU STAFFA ART. 4786
INSTRUCTIONS FOR INSTALLING AN INTERNAL DIVA AUDIO
UNIT ART. 4781 ON A MOUNTING BRACKET ART. 4786
INSTRUCTIONS D'INSTALLATION DU POSTE INTÉRIEUR
AUDIO DIVA ART. 4781 SUR SUPPORT DE MONTAGE
ART. 4786
FI
GB
11,5 mm 17,5 mm
74,5 mm
260 mm
11,5 mm
17,5 mm
95 mm
==
503
C
