Art. 4893M
Description
Wall-mounted external unit for Quadra series door entry monitor. Die-cast aluminium front panel, wide-angle
colour video camera and single LED for lighting at night. Mechanical buttons with the option of setting 1 to 4
call buttons via DIP-switch. Indicator LED for call sent, lock-release activated, audio activated and system busy.
Loudspeaker volume adjustment and audio balancing. Bus line power supply. Dimensions: 95x195x28 mm.
2
1
3
4
5
6
1
1
2
1
2
3
4
7
1. Die-cast aluminium cover.
2. Default camera lighting LED, call activated (see Entrance panel settings on page 12).
3. Wide-angle colour video camera.
4. Speaker.
5. Indicator LED:
call sent / lock-release activated
audio activated / system busy.
6. Call button 1 / 2 / 4 users.
7. Microphone.
