IDENTIFICATION OF COMPONENTS
Refer to gures 1, 2, 3, 4 and 5.
1. Master switch
2. Transport grip
3. Warning plate. Informs about residual risks: not to be
used to wash people, animals, electrical apparatus
and the high-pressure cleaner itself. Warns that
the machine is unsuitable for connecting up to
the drinking water mains (to connect up to the
water mains, a
BA
type mains disconnector will be
required which can be purchased from your dealer).
4. Power cable
5. Oil level indicator
ETM71, ETM130, ETM150
6. Pressure adjustment knob
7. Water outlet connection
8. Identication plate. Shows the serial number and
main technical specications.
9. Spray gun
10. Lance hose
11. Nozzle holder head
12. Nozzle cleaning pin
13. High-pressure hose connection
14. High-pressure hose
15. High-pressure hose quick coupling
16. External detergent suction hose lter
ETM100,
ETM130, ETM150
17. External detergent suction hose
ETM100,
ETM130, ETM150
18. Spray gun lever safety stop
19. Spray gun lever
20. Water inlet connection
21. Water inlet lter
22. Water inlet quick-t connection seal
23. Water inlet quick-t connection
24. External tank detergent suction coupling
ETM100, ETM130, ETM150
25. Elastic clamp for fastening the detergent suction
hose
ETM100, ETM130, ETM150
26.
BA
type water mains disconnector (not supplied)
27. “Priming” device (ETM 130)
ETM130
28. Foaming lance
ETM71
29. Detergent intake adjuster
ETM71
30. Opening for detergent
ETM71
SAFETY DEVICES
• Ampere cut-out protection device.
This device stops the high-pressure cleaner operation in the event of excessive power absorption.
If it trips, proceed as follows:
- move the master switch (1) to “0” position and remove the plug from the power socket;
- press the spray gun lever (19), so as to release any residual pressure;
- wait 10÷15 minutes for the high-pressure cleaner to cool down;
- make sure the instructions for connection to the power supply are complied with (refer to the
INSTRUCTION
MANUAL SAFETY PRECAUTIONS
), with special reference to the extension used;
- t the plug back in the socket and repeat the start procedure described in the paragraph “
OPERATION
”.
• Pressure unloader/regulation valve.
Valve suitably set by the Manufacturer, which permits regulating the operating pressure by means of the
knob (6) and which allows the pumped uid to return to pump suction, preventing the occurrence of
hazardous pressures when the spray gun is closed or whenever an attempt is made to set pressure values
above max. allowed pressure.
• Spray gun lever lock device.
Safety stop (18) which allows locking the lever (19) of the spray gun (9) in closed position, thus preventing
accidental operation (g. 2, position S).
STANDARD FITTINGS
Make sure the following are contained in the purchased product pack:
• high-pressure cleaner;
• high-pressure delivery hose with quick coupling;
• spray gun;
• lance hose;
• suction connection kit;
• Foaming lance
ETM71
;
