WARNING
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
Read and keep in mind that indicated in the
INSTRUCTION MANUAL SAFETY WARNINGS.
TECHNICAL CHARACTERISTICS AND SPECIFICATIONS
10.150 12.130 12.200
ELECTRICAL CONNECTIONS
Power supply (*) 230 V - 1~ - 50 Hz 400 V - 3~ - 50 Hz
Input 2,9 kW 5,0kW
Fuse 16 A
HYDRAULIC CONNECTION
Maximum water supply temperature 60 °C - 140 °F
Minimum water supply temperature 5 °C - 41 °F
Minimum water supply ow rate 750 l/h
198 US gph
900 l/h
238 US gph
900 l/h
238 US gph
Maximum water supply pressure 0,8 MPa - 8 bar - 116 psi
Maximum priming depth 1,5 m - 4,9 ft
PERFORMANCES
Max. ow rate 10 l/min
600 l/h
159 US gph
12 l/min
720 l/h
190 US gph
12 l/min
720 l/h
190 US gph
Maximum pressure 15 MPa
150 bar
2176 psi
13 MPa
130 bar
1885 psi
20 MPa
200 bar
2901 psi
Reaction force on the gun 28,9 N 32,2 N 35 N
Sound pressure level - Uncertainty (**) 88,2 dB(A) - 0,8 dB(A)
Sound power level 94 dB(A)
Operator arm-hand system vibration -
Uncertainty(**) 2,3 m/s² - 0,24 m/s²
WEIGHT AND DIMENSIONS
Length x Width x Height 520 x 430 x 930 mm - (20,5 x 16,9 x 36,6 in)
Weight
Classic model
Extra model
35 kg - 77 lb
45 kg - 99 lb
(*)
The cable supplied with the three-phase versions does not have a plug tted; to assemble this component please contact a
QualifiEd ElEctrician
(see the
instruction Manual - safEty rEcoMMEndations
).
(**)
Measurements taken in compliance with EN 60335-2-79
The characteristics and specications are guidelines only. The manufacturer reserves the right to make all modications to the
equipment deemed necessary.
