Comet K 200 Classic User Manual

23
EN
• professional xed fan-shaped nozzle;
• water inlet quick-t connection kit;
• external detergent suction hose kit;
• handle for transporting and manoeuvring (Classic model);
• handle xing kit (Classic model);
• instruction manual - safety precautions;
• instruction manual - operation and maintenance;
• warranty certicate;
• after-sales centre booklet;
• EC declaration of conformity;
• nozzle cleaning pin.
In case of problems, contact your dealer or an authorised after-sales centre.
OPTIONAL ACCESSORIES
The standard ttings of the high-pressure cleaner can be integrated with the following range of
accessories:
•
BA type water mains disconnector: mandatory for connecting up to the drinking water mains.
• sandblasting lance: designed to clean surfaces, eliminating rust, paint, scale, etc.;
• drain cleaning kit: designed to unblock pipes and ducts;
• rotating-nozzle lance: designed to remove resistant dirt;
• foam lance: designed for more eective detergent distribution;
• lances and nozzles of various types.
INSTALLATION  FITTING ACCESSORIES
• Put the power cable support (10) on the sheet metal plate of the handle (8) and x it with the self-
tapping screw (11).
opEration a of fig. 2 .
• Insert the handle (8) in the steel pipes projecting from the machine and x it using the kit supplied:
tighten the threaded handwheels (12) on the nuts retained by their housings on the handle.
opErationB
of fig. 2 .
• In the Classic model, connect quick-t connection (22) of hose (20) to the water outlet connection.
opEration g of fig. 5 .
• In the Classic model, screw up the connection (21) of the high-pressure hose to the thread (18) of the
spray gun (13) and tighten well using two 22 mm xed wrenches (not supplied).
opEration f in fig. 5.
• In the Extra model, screw the high-pressure hose connection of the hose reel onto the coupling (19)
of the spray gun (13) and tighten well using two 22 mm xed wrenches (not supplied).
opEration l in
fig. 6.
• Fit the lter (30) in the water inlet connection (29). opEration d in fig. 4.
OPERATION  PRELIMINARY ACTIVITIES
• Move the high-pressure cleaner to work position.
• This machine can be used in vertical position
(fig. 2, rEfErEncE “a”) and in horizontal position (fig. 2,
rEfErEncE “b”). In case of continued and intensive operation for many hours a day, the use in horizontal
position is recommended.
• In the Classic model, Completely unwind the high-pressure hose (20).
• If your machine has a hose reel (5) release it by turning knob (27) anticlockwise; unwind enough hose
by turning the reel clockwise with the crank (26); lock the device by turning the knob (27) clockwise.
• Fasten a supply hose with inner diameter 15 mm/0.59 inches to the water inlet quick-t connection,
using an ordinary gardening quick-t connection.
opEration H in fig. 5.
• Open the water supply tap and make sure this is not dripping;
- if the connection is made to the drinking water mains, a
BA type water mains disconnector (38) must
be used, in conformity with EN 12729 standard, and available from your dealer
(fig. 6). With regard
to its use, refer to the relative instruction manual;
- in case of supply from a water tank, introduce the suction hose inside the tank and make sure the vertical
distance between the water level and the pump is no more than 1.5m (4.9ft).
opEration M in fig. 6.
• Make sure the master switch (1) is on “0” position and insert the plug. opEration i in fig. 5.
• Move the master switch (1) to position “1”.
