24
• Press the spray gun lever (17) and wait for a continuous jet of water to come out;
• Move the master switch (1) to “0” position and connect the lance hose (14) to the spray gun (13),
tightening well.
opEration E in fig. 5.
STANDARD OPERATION HIGH PRESSURE
• Make sure the nozzle holder head (15) is not in the detergent dispensing position (refer to
“OPERATION
WITH DETERGENT”
paragraph).
• Start the high-pressure cleaner again moving the master switch (1) to position “1”.
• Press the gun spray lever (17), making sure the spray of the nozzle is even and this is not dripping.
• If necessary, adjust the pressure by turning the knob (6). Turn clockwise to increase pressure,
anticlockwise to decrease it.
OPERATION WITH DETERGENT
The detergents recommended by the Manufacturer are over 90% biodegradable.
For instructions on how to use them, refer to the indications on the label of the detergent pack.
• Move the master switch (1) to “0” position.
• In the case of suctioning from the high power cleaner’s tank (40), remove the cap (39) and, being careful
not to spill any liquid (maximum capacity is 3.5 l/0.92 US gal), ll the tank with the solution wanted.
• To ensure thorough cleaning, the detergent tank (40) can be taken out after releasing it by turning the
device (41) anticlockwise.
opEration n of fig. 7
. Proceed in the opposite order to put it back in place.
• In the case of suctioning from an external tank (
fig. 7 - rEfErEncE “a”),
remove the cap (44) and put in
the coupling (43) the connection (25) of the detergent suction hose (23) from external tank as shown
in
fig.7- rEfErEncE “b”
; put the other end of the hose (23), including the lter (24), in the external tank
which you have already prepared with the detergent solution wanted: in this case too, follow the
indications given for the dosage on detergent pack label.
• Operate on the nozzle holder head (15) as shown in
fig. 3 - rEfErEncE“a”
.
• Start the high-pressure cleaner again, moving the master switch (1) to position “1” and operate the
lever(17): suction and mixing occur automatically as the water ows through.
• Turn the knob of the detergent tank cap (39) until the quantity of product wanted is dispensed.
• To stop the supply of detergent and restore high-pressure operation, stop the high-pressure cleaner
moving the master switch (1) to “0” position and operate on the head (15) as shown in
fig. 3 - rEfErEncE“b”
.
STOPPING OPERATION
• When, with working pressures higher than 20 bar/290 psi, you release the spray gun lever (17) the
high-pressure cleaner stops automatically thanks to the Total-Stop device. It starts operating again
when pressing the spray gun lever.
STOP
• Completely close the water supply tap (or remove the suction hose from the water tank).
• Empty the water from the high-pressure cleaner, allowing this to operate for a few seconds with the
spray gun lever (17) pressed.
• Move the master switch (1) to “0” position.
• Remove the plug from the power socket.
• Eliminate any residual pressure in the high-pressure hose, by keeping the spray gun lever (17) pressed
for a few seconds.
• Wait for the high-pressure cleaner to cool down.
DECOMMISSIONING
• In the Classic model, re-wind the high-pressure hose (20) carefully, avoiding any folds.
• If your machine has a hose reel (5) release it by turning knob (27) anticlockwise; rewind the high-pressure
hose neatly, taking care not to get it twisted, turning the hose reel anticlockwise with the crank (26);
lock the device by turning the knob (27) clockwise.
• Rewind the power cable (28) carefully onto its support (10).
• Store the high-pressure cleaner in a dry and clean place, making sure not to damage the power cable
and the high-pressure hose.
