Comet static 1700 User Manual

15
PARTS IDENTIFICATION
Refer to gs. 1, 2 and 3.
1 Main ON/OFF switch
2 Lifting and transport handle
3 Left safety hook
4 Warning plate. It informs of residual risks; it is
forbidden to use the machine without having read
the instruction manual rst; it is forbidden to use
the machine to wash people, animals, electrical
equipment or the high pressure cleaner itself
5 Identication nameplate. It bears the serial number
and the main technical specications
6 Electrical power supply cable
7 Right safety hook
8 Release button
9 Wall-mounting frame securing screw
10 Check ring
11 Wall-mounting frame
12 Hose reel
13 Wall-mounted accessory frame
14 Wall-mounted frame securing wall-plug (orange)
15 Hose reel handle
16 Wall-mounted frame securing nut
17 Pump water inlet tting
18 Water inlet lter
19 Foam spray nozzle
20 Detergent suction adjustment device
21 Detergent ask
22 High pressure gun lever
23 High pressure gun lever safety lock
24 High pressure gun
25 Water inlet quick-release tting
26 Water inlet hose holder gasket
27 Water inlet hose holder bend
28 Spray nozzle pipe
29 Rotating spray nozzle pipe
30 Nozzle holder head
31 Nozzle cleaning pin
32 Nozzle disassembly key
33 Rotating high pressure cleaning brush
34 High pressure hose
35 Handle securing screw (length 2 cm/0.8”)
36 Wall-mounted accessory frame securing screw
(length 4 cm/1.6”)
37 Wall-mounted accessory frame securing wall-
plug (grey)
SAFETY DEVICES
• Thermal protection.
It is a device that stops the high pressure water cleaner if the electric motor overheats. If this
occurs, proceed as follows:
- Place the master switch (1) in position “0” and disconnect the plug from the wall socket;
- Press lever (22) of the gun to discharge possible residual pressure;
- Wait 10-15 minutes to allow the high-pressure cleaner to cool;
- Check that the requirement for the mains power connections have been respected (see the
INSTRUCTION MANUAL - SAFETY WARNINGS), paying particular attention to the extension
lead used;
- Reconnect the plug and repeat the start procedure described at paragraph “OPERATION”.
• Pressure restriction/adjustment valve.
It is a valve that is appropriately calibrated by the manufacturer, which allows the uid pumped
to return to the suction line of the pump, which avoids dangerous pressures when the high
pressure water gun is shut-o or when attempting to set pressures above the admitted values.
• Gun lever blocking device.
This safety catch (23) allows to block the lever (22) of the gun (24) in the closed position,
preventing accidentalactivation (Fig. 2, position S).
