3. Parts Names
1.
Red: Talk (Audio)
2. Blue: GND
3. Yellow: Power (+12V)
4. White: Video
▷
Polarity of the camera connector
5. Wiring and Connection Instructions
Wall bracket
for monitor
4. Pa
4 6
•You
can adjust DOOR VIDEO SET, UTILITY and check INFORMATION(model
name &version) with (UP)△ / (DOWN)▽ button after pressing Menu button on the
front of the product in video talk mode or stand-by monitoring.
•Products settings need the following 4 buttons on the right of product.
* Start Menu / Exit : MENU button * Select and in-put : SELECT (Interphonebutton)
* Move up / Move right : △/▷(Open button)
* Move down / Move left : ▽/◁(Monitoring button)
Press the Menu button and access to DOOR VIDEO SET and enter the setting menu by
pressing SELECT button.
(1) BRIGHTNESS : Adjusting Brightness of Screen
(2) CONTRAST : Adjusting Contrast of Screen
(3) COLOR : Adjusting Color of Screen
※ How to adjust
① Move to Menu you want to adjust with △/▽
button on the list of DOOR VIDEO SET
② Press SELECT button to choose an icon.
③ Adjust the set value with
◁/▷button
④ To complete the set, press SELECT button.
7. Settings
3 . Monitorin
: function to see the image of
visitor in the entrance
.
(stand-by mode) Operation
- By pressing the Monitor button repeatedly, the monitor will work as following in order.
Camera 1 ( Camera 2 ) OFF Camera 1 ............
(On talking mode)Operation
- By pressing Monitor button repeatedly, the monitor will work as following in order.
Camera1 ( Camera 2 ) Camera 1 ( Camera 2 ) ............
(4) RESET : Initializing
※ How to Reset
①
Move to RESET menu in DOOR VIDEO SET menu
② Press SELECT to enter the menu.
③ Select YES with
◁/▷button
④ Press SELECT button.
③ Adjusting call level : 0(MUTE) ~ 3(MAX)
④
To complete the set, press SELECT button.
① Move to CHIME-BELL VOLUME icon with △ /▽
button in UTILITY Menu.
② Press SELECT to enter the menu.
(5) EXIT : Go back to setting mode
Press the Menu button and access to Utility SET and enter the menu by pressing
SELECT button.
(1) CHIME-BELL VOLUME : setting call sound level
1. Screen setting (Brightness/Contrast/Color adjustment function)
2. UTILITY(additional function)
To Next Page
