4. Wiring and Connection Instructions
. Installation
5
1.
Red: Talk (Audio)
2. Blue: GND
3. Yellow: Power (+12V)
4. White: Video
▷
Polarity of the camera connector
1.
Red: Talk (Audio)
2. Blue: GND
3. Yellow: Power (+14V)
4. White: Call signal
▷
Polarity of interphone connector
☞ When adding a second monitor,
deteriorate
☞ When using UTP CABLE[CAT.5] for
rest 4 lines to GND after connecting
INTER
PHONE
IN
G
B+
CALL
IN
G
B+
CALL
INTERPHONE
MONITOR
visual and audio quality of video may
better image quality, connect the
4 lines with monitor and camera.
CAM1
CAM2
IN
G
B+
VD
IN
G
B+
VD
CAMERA
MONITOR
DOOR Camera Wiring
Cautions
①
Avoid the direct sunlight.
② Recommended height is around
③ Avoid the installation near magnetic
1450~1500mm
activity, humid temperature and gas.
SCREW M3 (1EA)
SCREW
T4
(4EA)
4
INTERPHONE
Wiring
