Press the interphone button and door release button at the same time for about 3 seconds.
Then, image setting value and sound volume will be initialized.
7. Initialization (RESET)
7
CDV-43U
Model
Spec
8. Specification
Entrance : electronic chime,
Interphone : electronic buzzer
60 ±5sec (During conversation)
30 ±5sec (During monitoring)
28m(
Ø
0.5) / 50m(
Ø
0.65) / 70m(
Ø
0.8)
Working temperature
0 ~ +40°C (32°F ~ 104°F)
Ringing sound
Screen Display
(
3) SCREEN MODE : to set for screen ratio.
* H
ow to adjust
① A
ccess to SCREEN MODE with UP /DOWN button in UTILITY Menu.
② P
ress the SELECT button to enter the menu.
③ A
djust screen ratio value with UP/DOWN button.
④ T
o complete the set, Press the SELECT button.
- ZOOM :
Z
oon in(expansion) image maintaining actual ratio(4:3) is shown. (full of the screen).
- 4
:3 : Image of 4:3 ratio without expansion is shown.(This is actual ratio for camera).
- WIDE: Full of the screen. Not actual ratio (4:3).
Image is expanded according to LCD (WIDE LCD) ratio.(16:9)
(4) EXIT: Go back to the UTILITY Setting menu.
4-3. INFORMATION (The function to check Model name & Version)
In order to check the product information, Press the menu button and move to
INFORMATION menu with UP/DOWN button.
(1) MODEL : You can check the model name.
(2) VERSION : You can check the model version.
(3) SYSTEM : SINGLE (FINE VIEW VIDEOPHONE)
(4) TOUCH : You can check the touch-key version.
(5) VIDEO : You can check the video transmission formats(NTSC/PAL)
(6) SOURCE : You can check the position of camera(DOOR1 / DOOR2) which is
shown on the screen for now.
4-4. EXIT (Finish setting menu)
Distance(Cable thickness)
Dimension
180.0(W)X180.0(H)X28.5(D)
Call mode HANDS FREE Call mode (Voice switch circuit)
Screen size 4.3" TFT-DIGITAL LCD
Transmission Entrance 4wires polarity, interphone 4wires polarity
Consumption Operation: 10W(MAX)
Rating Voltage 100-240V~, 50/60Hz (FREE VOLTAGE)
