Commax CDV-70A User Manual

3
Power & Installation
Please don’t use several
products at the same time on
one power socket.
·
It may cause a fire due to an
abnormal overheating.
Please don’t bend the power
cable excessively or it may
cause an electric shock.
·fire when using a damaged
power cable.
Please don’t handle the power
cable with a wet hand.
·
It may cause an electric
shock.
Please plug out the power
cable from the socket when
not using it for a long period
of time.
·
It may shorten the product
lifespan or cause a fire.
Please don’t install the
product in the place where
there is much oil, smoke or
humidity.
·It may cause an electric
shock or fire.
Please don’t install the
product with the lightening
and thunder.
·It may cause an electric
shock or fire.
Please don’t use and connect
this product with other
products with different rated
voltage
·It may cause a disorder or
fire.
When installing the product
that generates heat, please
install the product away from
the wall (10cm) for the
ventilation.
·
It may cause a fire due to
the increased internal
temperature.
Warning &
Caution
Parts Names
2.
Menu Button
Power Switch
Monitor Button
Interphone Button
Talk Button
Talk Sound Control
Speaker
Microphone
On/Off & display LED
Call Sound Control
Select Button
CDV-70A(70AD) Wall Bracket Manual
T4X18
Wall bracket
mounting Screw
M3X8
Monitor
Fixing Screw
Connector
4P(3EA)
Door Release Button
Up & Down Button
3. ckage ContentsPa
Priority button(PTT)
Connector Terminal
(camera/Interphone/prog.)
DC Terminal
※
DC Power terminal(Non polarity) : DC 17~30V (only CDV-70AD)

Commax CDV-70A Specifications

General

Brand	Commax
Model	CDV-70A
Category	Intercom System
Language	English
