Commax CDV-70P User Manual

① Body of CDV-70P
⑤ PHM 3 X 6 ZnY
Screw for body
② Bracket for wall mount
③ Manual
④ GH1T 4 X 18 ZnY
Screw for wall mount
① Monitor(CDV-70P)
② Wall bracket
③ Manual
④ Mounting Screw (SCREW GH1T 4X18 ZnY) – 4EA
⑤ Monitor fixing screw (SCREW PHM 3X6 ZnY) – 1EA
⑥ Connector (CONN. 4PX300) – 2EA
⑦ Camera 2 Short pin (PIN 2P SHUNT(A2095)) – 1EA
⑥ 4P(2EA)
Connector
11
⑦ 2P SHUNT
Only No. 1 camera is available
if you insert 2P shunt(short pin)
7. Part list
