9. Package Contents
1
4
5
2
3
6
① Main body (CDV-70H) ② Wall bracket ③Manual
④ Screw for wall bracket (SCREW GH1T 4*18 ZnW) – 4EA
⑤ Screw for body (SCREW PHM 3*6 ZnY) – 1EA
⑥ Camera connector (CONN. 4P*200) – 1EA
10. Specification
interphone 4wires (polarity)
Rating Voltage 100V-240V~, 50/60Hz (FREE VOLTAGE)
Power consumption Stand-by : 3 W Maximum: 16 W
Transmission way HANDS FREE (Voice switch circuit)
Screen size 7" TFT-DIGITAL LCD
Ringtone
Door : Electronic chime (Sol Mi Do),
Interphone : Beep
Display Monitoring : 30 ±5sec Talk : 60 ±5sec
Distance(Cable thickness)
Pie 0.5mm 0.65mm 0.8mm
28m 50m 70m
orking temperature 0 ~ +40
℃
(32°F ~ 104°F)
10. Safe Operation guide
●
Make sure to turn on the product
●
In case if physical damage or operation failure is detected, do not hesitate to
contact Service Center
●
All electric power must be blocked by the building blocking device
●
Do not place water bottles or flowerpots upon the product
●
●
This apparatus shall not be exposed to dripping or splashing and that no objects
●
Plug as disconnection device shall remain to be readily approached by user.
Please, turn the power off when installing or repairing the product
filled with liquids, such as vases, shall be placed on the apparatus.
8
CDV-70H :
100-240V~, 50/60Hz(FREE VOLTAGE)
Power source
CDV-70HD : 24V --- , 1A
Power Consumption
Operating : W
Wiring 4 wires with door camera (Polarity),
4 wires with an Interphone (Polarity)
Screen Size
Color 7" TFT LCD
Communication Simultaneous communication
From a door camera : Electric chime
From an interphone : Beep sound
Call Sound
Time to display the screen 60 ± 10sec
Distance from camera 28m(Ф 0.5) / 50m(Ф 0.65) / 70m(Ф 0.8)
Reference : Design and functions of the product are a subject of constant
development as a pursuit of quality improvement
9. Specifications and Features
-70H / CDV-70HD
10 11
Operating Temperature
0 ~ +40℃ (32°F ~ 104°F)
Warranty Period
Environment Condition
Product Life-Cycle
1 year
S
torage Temperature
Stor
age Humidity
10 y
ears
-40 °C to 50 °C
Les
s than 90 %
