Commax Fineview CDV-70H User Manual

2. Parts Names
No.
PART
No.
PART
No.
PART
1 MONITOR(LCD) 5
INTERPHONE BUTTON /
SELECT BUTTON
9 SPEAKER
2 POWER LED 6
DOOR RELEASE
BUTTON/
UP BUTTON/
10 POWER SWITCH
3 MICROPHONE 7 MENU BUTTON
4
MONITOR BUTTON/
DOWN BUTTON
8 TALK BUTTON
1. MONITOR(LCD)
2. POWER LED : show green light when the monitor is turned on, no light when off
3. MICROPHONE
4. MONITOR BUTTON (DOWN BUTTON) : Press to see images from
camera. . And press to move (down / left) on menu.
5. INTERPHONE BUTTON (SELECT BUTTON) : Press to call interphone.
And press to select on menu.
6. DOOR RELEASE BUTTON (UP BUTTON) : Press to open the door. And
press to move (up / right) on menu.
7. MENU BUTTON : Press to enter Menu for display adjustment, calling sound
setting, product Information etc.
8. TALK BUTTON : to call and answer for visitor.
9. SPEAKER.
10. POWER SWITCH.
4

Commax Fineview CDV-70H Specifications

General

Brand	Commax
Model	Fineview CDV-70H
Category	Intercom System
Language	English
