Commax TP-90RN User Manual

4 .
6
REJECT PAGING
SELF ADDRESS No.64 S/W
SELF ADDRESS No.32 S/W
SELF ADDRESS No.16 S/W
SELF ADDRESS No. 8 S/W
SELF ADDRESS No. 4 S/W
SELF ADDRESS No. 2 S/W
SELF ADDRESS No. 1 S/W
No. 2 +
No. 8 + No.16 + No.64 = No.90
No. 1 + No. 2 + No.8 + No.32 = No.43
Ex.) Station ID no. 43 dip switch set to receive a paging.
Ex.) Station ID no. 90 dip switch set to receive a paging.
How to arrange the self address no.
[Addressing]
1 2 8 32
p
2 8 16 64
ON
1 2 3 4 6 8
5
7
ON
1 2 3 4 6 8
5
7
ON
4
16
64
1 32
p
4
Two or three stations can be operated on the same ID number. This allows more units to be connected
- Set the same ID number to the units.
to the system.
- When the call is answered the other station(s) are free.
- All units will ring when the ID number is called.
3-10. Parallel Connection
- The free units can operate as normal.
- You can address the self station No. by use the
DIP S/W back of the unit.

Commax TP-90RN Specifications

General

Brand	Commax
Model	TP-90RN
Category	Intercom System
Language	English
