3
Introduction
Part name
① TFT LCD
② Speaker
③ Emergency button
④ Call guard station
⑤ Door release button
⑥ Call button
⑦ Home Button
⑧ Microphone
⑨ Power Switch
⑩ PoE
⑪ PIR
1. Sensor_in, 2. GND, 3. VCC
⑫ EM
⑬ RS-485
1. TRX-, 2. TRX+, 3.GND
⑭ DDL VCC (OPTION)
⑮ DDL S/W (OPTION)
