SET-UP
SEATPOST AND SADDLE
To adjust your saddle height,
untighten the seat clamp (by
hand or with an allen key),
adjust the height and tighten
the seat clamp.
To set the correct height, sit on
your bike and put one pedal as
low as possible: your leg should
be straight.
For your health and comfort,
it is important to correctly
orientate your saddle. An
inapproriate setting could result
in uncomfort or pain when
using your bike.
To set your saddle positon,
unscrew bolts (A and B). First,
set the lateral position along
the rails to your preference.
Second, tighten to achieve a
horizontal orientation.
!
4 4
The maximum insertion line
should not be visible.
Your dropper seatpost should be
actuated to complete this set-up.
SADDLE HEIGHT SADDLE POSITION
COMMENCAL / P.17
