Monitor parts may be secured locally. JVC part numbers have been provided for your convenience. ONLY Com-
modore part numbers (C314-xxx-xx) will
be available from Commodore at this time.
MAIN PCB ASSEMBLY #GE-1000A (Continued)
LOCATION DESCRIPTION
RESISTORS
R1410
R1414
R1415
R1421
R1503
R1509
R1511
R1512
R1514
R1515
R1522
R1523
R1528
R1532
R1703
T1704
Metal Film. 6.8. 1W. ± 5%
Oxide Metal Film. 3.3K. 1W. ± 5%
Oxide Metal Film. 2.7K. 1W. ± 5%
Oxide Metal Film. 6.8K. 2W. ± 5%
Metal Film. 11.8K. 1/4
W. ± 1 %
Oxide Metal Film. 10K. 2W.
±5%
Oxide Metal Film. 8.2K. 2W. ± 5%
Oxide Metal Film. 8.2K. 2W. ± 5%
Oxide Metal Film. 680. 2W. ± 5%
Metal Film. 8.2. 1 W. ± 5%
Metal
Film. 4.7. 1W. ±5%
Oxide Metal Film. 18. 2W. ± 5%
Oxide Metal
Film. 390. 1 W. ± 5%
Zinc. 270. ± 10%
Metal Film. 41.2K. 1/2W.
±1%
Metal Film. 9.53K. 1/4W. ± 1 %
VARIABLE RESISTORS
R1209 1K
R1303 50K
R1305 20K
R140S
220
R1422
220
R142S 50K
R1524 4.7K
CAPACITORS
C1202 Tantalium •. 47 p,F. 35V. ±20%
C1204 BiPolar Electrolytic. 3.3 p,F. 50V. ± 20%
C130S
Trimmer
Cap
C1351 BiPolar Electrolytic. 10 JtF. 16V. ± 20%
C1402
Tantalium. 2.2
JtF. 16V. ± 10%
C1407
Electrolytic. 3.3
p,F. 50K. ± 10%
C1411 Electrolytic. 100
p,F. 160V. +30%.
-10%
C1412 Electrolytic. 3.3 p,F. 160V. + 30%. -10%
C150S Polypropylene. 5600 pF. 50V. ± 5%
C1511
Electrolytic. 47
JtF. 160V. +30%. -10%
C1512 Metalized Polypropylene. 1500 pF. 1600V.
±5%
JVC PART #
ORX019J-6R8S
ORG019J-332
ORG019J-272
ORG029-J-682
ORV141F-1182
ORG229J-103
ORG229J-822
ORG229J-822
ORG229J-6S1
ORX019J-SR2
ORX019J-4R7
ORG029J-180
ORG019J-391
ERS-C05DK271
ORV121 F-4122
ORV141 F-9531 Y
OVZ3234-013
OVZ3234-054
OVZ3234-024
A76195-221
A76195-221
OVZ3243-254
A76195-472
OEE61 VM-4 74RZ
OEN61 HM-335Z
OEN61 CM-1 06Z
OEE61 CK-225B
OEM41 HK-335M
OET52CR-107
OET52CR-335
OFP31 HJ-5625
OET52CR-476
OFZOOS2-1525
*SAFETY
COMPONENTS - Use EXACT replacement ONLY.
COM PART #
25
