CommScope ValuLine VHLP3 Series User Manual

Table 1 Supplied Equipment and Tools
Page 7 of 20
7706805
EQUPMENT AND TOOLS
SECTION 3 INSTALLATION
INSTRUCTIONS
Item Qty Description Contained in Kit Part No
A 1 Reflector
B 4 Radome Rim
C 1 Radome
D 1 Feed VF-3-FR-14
D1 1 Feed Installation Kit
E 1 Mount: Elevation Adjustment Assembly 7679156
F 1 Mount: Azimuth Adjustment Clamp 7671897
G Mount Hardware Kit 7700025
1 Conductive Grease (Tube)
2 Gloves
G1
2 M10 x 100lg Hex Hd Screw, sst, pass
4 M10 Flat Washer, stl, sst, pass
2 M10 Lock Washer, sst, pass
2 M10 Hex Nut, stl, sst, pass
G2
1 M10 x 35lg Hex Hd Screw, stl, galv
1 M10 Lock Washer, stl, galv
2 M10 Flat Washer, stl, galv
G3
1 M10 x 140lg Eyebolt, stl, galv
2 M10 Lock Washer, stl, galv
2 M10 Flat washer, stl, galv
2 M10 Hex Nut, stl, galv
G4
1 Pipe Clamp, stl, galv
4 M10 x 130lg Hex Hd Screw, stl, galv
4 M10 Lock Washer, stl, galv
4 M10 Hex Nut, stl, galv
G5
2 M10 x 35lg Hex Hd Screw, sst, pass
2 M10 Lock Washer, sst, pass
2 M10 FlatWasher, sst, pass
G6
1 M10 x 50lg Hex Hd Bolt, sst, pass
1 M10 Lock Washer, sst, pass
1 M10 FlatWasher, sst, pass
H Radome Rim Assembly Hardware 7700748
16 #12 x 16lg Self Tapping Screw, sst, pass
16 M6 Lock Washer, sst, pass
16 M6 FlatWasher, sst, pass
