INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 128
INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Delay Measurement Bins for IFDV
A Measurement Bin is a counter that stores the number of delay measurements falling within a specified range,
during a Measurement Interval.
If the measurement threshold is 5000 us and the total number of Measurement Bins is four, we can give an example
as follows.
Bin Threshold Range
bin0 0 us 0 us <= measurement < 5,000 us
bin1 5,000 us 5,000 us <= measurement < 10,000 us
bin2 10,000 us 10,000 us <= measurement < 15,000 us
bin3 15,000 us 15,000 us <= measurement < infinite us
Refresh Click to refresh the page immediately.
Back Click to go back to this MEP instance main page.
Apply Click to apply changes.
Reset Click to undo any changes made locally and revert to previously saved values.
