INS_CNGE11FX3TX8MS[POE][HO] Rev. 11.6.17 PAGE 297
INSTRUCTION MANUAL CNGE11FX3TX8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Appendix A
Ethernet Ring Protection Switching Example Configuration
Introduction
This section shows how to configure the Ethernet Ring Protection Switching (ERPS) for ComNet
switches using the Web GUI and the CLI commands. The following figure shows a simple three
switch network constructed to demonstrate these features.
Ethernet Ring Protection Switching (ERPS) Model
