Compac C4000 User Manual

Parameter Switch
Set-up Modes
Compac Industries Ltd.
Page 36
www.compac.co.nz
Setting the Price for True Multi-Product Configuration
Step
ACTION
RESULT
1
Ensure that the nozzles are
hung up
Dispenser in idle state
2
Press and Hold the „Side A‟
Parameter switch until the
“Price per litre” is displayed.
The Price for hose 1 side „A‟ is
displayed as „PX.XXX‟ and „Pr1‟ is
displayed on the price display.
3
Press and hold the
Parameter switch.
A digit, of the displayed „Price per
litre‟, will begin to increment.
4
When the digit is correct,
release the Parameter
switch.
5
Repeat steps 3 and 4 for
each digit of the „Price per
litre‟.
The C4000 will reset
itself if the Parameter switch is left
for more than 60 seconds.
Continue for each hose
6
Press and release the
Parameter switch 8 or more
times in quick succession
The „Price per litre‟ for the next
hose on side „A‟ is displayed as
„PX.XXX‟. „Pr2‟ or „Pr3‟ is
displayed on the price display.
7
Repeat steps 3 to 5 above.
Continue for side “B”
8
Repeat steps 1 to 7 for side
“B”
If a Compac Central Controller, EFTPEC, Task forecourt
controller, or Compac Commander is used, the price must be set to zero (0) at
the pump/dispenser. The price can then be set at the Controller. This applies to
all configuration display options.
The dispenser/pump will stop when the dollar amount reaches:
$999.99 (high-flow $9999.9) or the litre amount reaches 999.99l (high-flow
9999.9l) whichever occurs first.
