Compac CNG User Manual

Electrical Drawings and Component Details
C4000 IS Cable Connections
Compac Industries Ltd.
Page 115
www.compacngv.com
C4000 IS Cable Microprocessor End
18 17
20 19
22 21
24 23
10 9
12 11
14 13
16 15
2 1
4 3
6 5
8 7
Red / Black / White GND
White / Red VL
Red / Green GND
Green / Black / White GND
Orange / Red VL
White / Black / Red GND
J2A
Green POK
Black / White T9
Red / White T7
Blue / Red GND
Green / White T10
Blue / Black T8
Green / Black T5
Red / Black T3
Orange T1
Orange / Black T6
Blue T4
White / Black T2
Orange / Green VP
Blue / White GND
Black / White / Red VP
Black / Red GND
2 1
4 3
6 5
8 7
Red VCC
Black RXD
White TXD
J2B
C4000 IS Cable - Gilbarco Interface Option
5
6
3 4
1
2
Black RXD
Red / Green GND
Red VIS (VCC)
White TXD
White / Black / Red GND
J2
