Compac CNG User Manual

Technical Specifications
Specifications
Compac Industries Ltd.
Page 82
www.compacngv.com
Technical Specifications
Operating Conditions
Compac CNG Dispensers (excluding hose assembly) are designed to operate
within the atmospheric environment. Gas parameters are outlined below.
CNG Dispensers require the following operating conditions:
Air temperature range
- 25 °C to + 55 °C
Air humidity range
10% to 95%
Gas type
High pressure natural gas (CNG)
Gas temperatures
- 40 °C to + 80 °C (continuous)
- 55 °C to + 80 °C (intermittent)
Maximum Water Dew Point
- 32 °C at 250 bar
Maximum Working Pressure
(Inlet)
275 bar (350 bar option)
General Specifications
Power Requirements
230V +/-10%, 50Hz, 2A
Specific Specifications
Standard Model
High-flow Model
Ultra high-flow Model
Flow
(The maximum flow rate is not only
determined by the type of
dispenser but also depends on the
size of the refuelling hose, the
model of the breakaway, the type
of refuelling nozzle, and the vehicle
coupling.)
1 – 15 kg /min
1-50 kg /min
1 – 80 kg /min
Pressure rating
(350 bar options utilise air actuated
valves and require a compressed
air supply.)
275 bar
(350 bar option)
275 bar
(350 bar option)
350 bar
Accuracy
+/- 1.0%
+/- 1.0%
+/- 1.0%
Meter
Compac KG80 coriolis
mass flow
Compac KG80 coriolis
mass flow
Compac KG80 coriolis
mass flow
Internal Pipework
1/2”
1/2”
1/2” or 3/4"
Refuelling hose
3/8”
1/2”
1/2” or 3/4"
In-line breakaways
Various available
Various available
Heavy duty
Refuelling valve
NGV1 or NZ 7/16" probe
NGV1 or NGV2
NGV2
Laser (without hoses or high
masts)
830W x 450D x 1608H
830W x 450D x 1608H
830W x 450D x 1608H
Legend (without hoses)
850W x 425D x 2355H
850W x 425D x 2355H
850W x 425D x 2355H
Minimum flow cut-off
0.5 -10 kg/min (settable)
0.5 -10 kg/min (settable)
0.5 -10 kg/min (settable)
Maximum flow cut-off
10 - 99 kg/min (settable)
10 - 99 kg/min (settable)
10 - 99 kg/min (settable)
