To adjust the meter K-Factor
1. Make sure that the dispenser is idle, with the nozzle in its holster.
Press and release the K-Factor switch until the required meter K-factor is
shown (F or FA or Fb )
1. Enter the required K-Factor.
Each press of the K-Factor switch passes you over a
digit in a setting, making the digit blink. Holding the switch down for
more than a second changes whichever digit is currently displayed. If
you want to pass over a setting without changing any digits, keep
pressing and releasing the switch.
The minimum flow rate (LFA and LFb) is the low flow cut-off at the
end of the fill.
LFA is the minimum flow rate of side A of the dispenser.
LFb is the minimum flow rate of side B of the dispenser.
These values are adjustable and can be set between 0.5 - 9.9 kg/min.
Do not set the minimum flow rate so that it is equal to or
above the maximum flow rate.
To adjust the Minimum Flow Rate
1. Make sure that the dispenser is idle, with the nozzle in its holster.
2. Press and release the K-Factor switch until the required minimum
flow rate is displayed. ( LFA or LFb )
3. Enter the new minimum flow rate.
Each press of the K-Factor switch passes you over a
digit in a setting, making the digit blink. Holding the switch down for
more than a second changes whichever digit is currently displayed.
If you want to pass over a setting without changing any digits, keep
pressing and releasing the switch.
The Compac factory default setting is 1.0 kg/min.
4. Let the menu time out so that the value and quantity amounts are
displayed.
The maximum flow rate (HFA and HFb) is the high flow cut-off for when
the flow through the dispenser is too high.
HFA is the maximum flow rate of side A of the dispenser.
HFb is the maximum flow rate of side B of the dispenser
These values are adjustable and can be set between 5 - 99 kg/min.
Do not set the maximum flow rate so that it is equal to or
below the minimum flow rate.
