C4000 IS Cable CNG Outputs
The C4000 controls the solid state relay switch. Solid state relay switches
control the C4000 220-240 volt outputs.
Solid State Relays (Triacs)
There are 10 separate solid state relays (small triacs) on the C4000 PCB.
The output terminals for these triacs are T1 to T10. See below for
information about the use of these outputs.
Power
Terminal
Function
T1
Solenoid Low Bank Side A
T2
Spare
T3
Solenoid Medium Bank Side A
T4
Solenoid High Bank Side A
T5
Spare
T6
Solenoid Low Bank Side B
T7
Solenoid Medium Bank Side B
T8
Spare
T9
Solenoid High Bank Side B
T10
Auxiliary Output for Compressor Controller
Fuses
Fuse
Rating
Comment
F1
0.5 A
Fuses F1, F2, and F3 should be 5 x 20 mm
glass normal blow type, and should comply
with IEC127, 35 Amp minimum rupture current.
F2
0.25 A
F3
1.0 A
