9. Service and maintenance
40
Service packages
Package C Oil filter cartridge, air filter cartridge
Package D Oil separator element
Package E Worn parts
Package V V-belt set (recommendation)
Intervals are valid for normal industrial environments
and operating conditions.
For order numbers see the spare parts list.
Maintenance items
W1 European-version
Oil change (CompAir - 4000 hours oil)
Valid for normal industrial environments (when in
doubt, check the oil change intervals by carrying
out an oil analysis) Minimum oil change = 1 x year
W2 Replacement of oil filter cartridge
Valid for normal industrial environments
W3 Replacement of oil fine separator cartridge
Valid for normal industrial environments
W4 Replacement of air filter cartridge
Valid for normal industrial environments
W5 Safety valve / functional test
at least once a year
W6 V-belt
(only visual check)
W7 Checking/tightening of connecting terminals in
the switch cabinet/ and checking of the
“control transformer” setting
W8 Checking/tightening screw connections
W9 General maintenance/cleaning
(In the case of a very dirty atmosphere, the
cleaning intervals have to be shortened as
required)
W10 Replacing the V-belt (recommendation)
(only complete sets)
W11 Cleaning/replacement of cooling air inlet filter
(In the case of a very dirty atmosphere, the
cleaning intervals have to be shortened as
required)
Intervals
Operating
hours
1000
2000
3000
4000
5000
6000
7000
8000
9000
10000
11000
12000
No later than
x months
During
comm.
3 M
6 M
9 M
12 M
15 M
18 M
21 M
24 M
27 M
30 M
33 M
36 M
Package C






Package D



Package E

Required service
package
Package V

W1



W2






W3



W4






W5



W6




W7




W8




W9



W10

Maintenance
W11






These maintenance intervals must be adhered to!
