Compak E8 OD - Page 10

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 07/01/2016 | K06307
8
7.3.Wheretouse
The grinder should be installed on a at, stable surface. The minimum
dimensions of the work space should be as follows:
Model
E5
E6 OD, E8 OD,
E10 CONIC OD
E10 MASTER
CONIC OD
Height
20.27
515
25.78
655
27.55
700
in
mm
Width
7.08
180
9.25
235
9.25
235
in
mm
Depth
15.55
395
16.53
420
16.53
420
in
mm
7.4.Grinderinstallation
Before grinder installation, the following should be considered:
• Thegrinderinformation plaquedatacoincideswith theelectricalsystem on
site.
• Theelectricaloutletcoincideswiththegrinderplug.
• The electric power at the location of installation should meet the minimum
requiredtoproperlyrunthegrinder.
• Theinstallationsiteshouldhavetheproperelectricaloverloadprotections.
• Thegrindershouldbeproperlygroundedasspeciedbylocalcode.
NOTE: The grinder should be used in environments with mínimum temperature
of 77-86F and should not be installed in places (such as industrial kitchens) where
cleaning is done with direct water spray cleaning.
