Compak E8 OD - Maintenance

K06307 | v. 07/01/2016 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS
23
NOTE: Based on extensive experience and a medium-hard coffee blend, we
recommend replacing the burrs following the quantities in next table:
Steel RedSpeedLucidate
E5 OD 350 Kg
E6 OD 400 Kg
E8 OD 800 Kg 5,000 Kg
E10 CONIC OD 1,200 Kg 8,000 Kg
E10 MASTER CONIC OD 1,200 Kg 8,000 Kg
12.3.Grindinggroupmaintenance
Not following the recommended burr life guidelines can compromise the safety of
the grinder.
Theseoperationsshouldbedonebyaqualiedservicetecnician.
To perform grind chamber maintenance please observe the following steps:
Turn off the grinder by making sure the main power switch ( ) is on the OFF
position. Disconnect the plug from the power source. Loosen the hopper security
screw ( ) using a flat head screw driver as seen in Fig.2 and remove the hopper
( ) from the grind regulator ( ). Loosen the screws on the grind regulator ( )
using a Torx T20 screw driver following Fig.10.
