8. REGULATION
8.1.Adjustingthelowerportaltersupport
Inordertoensuretheproperdistributionofgroundcoffeeintheportalter,while
supporting the portalter in a hands-free position during dosing, it is possible to
adjusttheheightofthelowerportaltersupport( ).
To do this adjustment operation:
1. Loosen the screw ( ) on the lower support ( ) by using the Allen Key included
with your grinder.
2. Adjustthe supportto thedesiredheightusingthe portalteras thepoint of
reference.
3. Tighten the screw ( ) with the Allen Key provided (Fig. 1).
NOTE: Iftheadjustmentisextreme(toohighortoolow),difcultiesinoperatingthe
dosis button might occur.
