Compak E8 OD - Page 13

K06307 | v. 07/01/2016 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS
11
*NOTE: Changing grind settings must be done when the grinder is on and burrs are in motion.
Not doing this suposes that the burrs will gunk up and cleaning will be required.
*Itisrecommendedthatthemotorberunningwhenadjustingtonergrindsetting.
This helps to avoid jamming the burrs, which can occur when coffee beans are in the
grindchamber,andthegrindregulatorisadjustedtowardsne.
8.3.2.Steppedgrindadjustment(optional)
In the stepped adjustment versions, the positions on the grind regulator are limited
by“steps”thataredenedbytheholeandpinpoints(Fig. 6).
The instructions detailed in section 8.3.1. on adjusting the regulator should be
followed, while at the same time, pulling the brake post ( ) (Fig. 6) up to release the
locking action of the post.
