9.2.Utilization
Through the program menu (section 10.3.), it is possible to select three distinct
functional modes: AUTOMATIC MODE, PRESLECT MODE and MANUAL MODE.
9.3.AUTOMATICMode
Selection of doses by lower pulse button ( ) (2 doses / 3 doses version):
• 1 ACTIVATION OF LOWER PULSE BUTTON ( ) -> 1 DOSE
• 2 ACTIVATIONS OF LOWER PULSE BUTTON ( ) -> 2 DOSES
• 3 ACTIVATIONS OF LOWER PULSE BUTTON ( ) -> 3 DOSES*
*Availableonlyforthe3dosesoftwareoption.
When beginning the grind cycle, the LCD screen ( ) will show current dose mode
(single,double,triple)accompaniedbythetimeconguredforthedose,whichwill
countdowntozeroasthedosecyclesthrough.
Once the grind cycle is initiated, it can be paused by pressing the activation button
( ). The cycle will pause, and will complete the timed grind cycle as long as the
lower activation button is pressed again within 10 seconds. After 10 seconds of
inactivity, the grind cycle will reset to the complete cycle time.
Pausing the grind cycle can be done by selecting MENU / SET UP SETTINGS / SET UP
GRIND PAUSE.
9.4.PRESELECTMode
In the PRESELECT mode, a pre-programmed single, double or triple dose can be set
by simple pressing the corresponding icon on the LCD screen ( ).
The preselection of a single, double or triple dose will remain active until it is changed
bypressingoneofthethreenumberedpreselecticons.Thispreselectionisreected
on the LCD screen ( ) with the icon of the active selection in the secondary color,
and the rest of the icons in the principle color.
Dispensing the preselected dose by pressing the lower pulse button ( ) one time.
When the grinding cycle begins, a timer countdown will begin on the LCD screen ( ),
whichwillcountdownthetimeddosecycletozero.
