8. REGULATION
8.1.Adjustingthelowerportaltersupport
Inordertoensuretheproperdistributionofgroundcoffeeintheportalter,while
supportingtheportalterinahands-freepositionduringdosing,itispossibleto
adjusttheheightofthelowerportaltersupport( ).
1. Loosen the two adjustment screws ( ) found on each side of the upper
portalterfork ( ), by using the Allen Key included with your grinder.
2. Adjustthe support tothedesiredheight using the portalterasthepoint of
reference.
3. Tighten the screw ( ) foundoneachsideoftheupperportalterfork ( ), with
the Allen Key provided (Fig. 1).
NOTE: Iftheadjustmentisextreme(toohighortoolow),difcultiesinoperating
the dosis button might occur.
