ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
18
Rotate the grind regulator clockwise until it is completely unscrewed (Fig. 11) until
the upper and lower burrs touch and can not be turned further. Clean the grind
chamber and threads of the housing using a soft cloth and vacuum cleaner until all of
the oils and residue has been removed.
Make sure to put new food grade lubricant on the clean threading of the housing and
upper assembly. Insert the upper burr assembly into the grind chamber, and turn
counter clockwise.
For positioning and mounting the grinding adjustment ( ) distinguish between
modelswithatburrs,K3, K6 and K8, and the conical burr models K10.
