Freezer/Refrigerator features
The DualZone Freezer/Refrigerator features two
(2) separate compartments, one can be utilised as
a freezer or refrigerator and the other section is a
refrigerator only. Both compartments are tted with
their own thermostat control.
Wire storage baskets are included as standard and
each compartment is equipped with plastic covers
allowing individual compartments to be accessed
without the need to open the other, minimising
temperature loss and power consumption.
The refrigerator compartment is cooled by the
transfer of cold air from the freezer section via a
fan that is tted in the dividing wall. It is important
that the wire storage baskets are used at all times
in both sections to allow the ow of air into the
compartment without obstruction.
Temperature setting
Freezer Section: the temperature range is adjustable
from +8 to -18**.
Refrigerator Section: the temperature range is
adjustable from +2 to -5**.
The following temperatures are to be used as a guide
only and will be affected by the ambient temperature,
contents of the compartments and the number of
times that the cabinet is opened.
* At maximum setting the fan will run continuously.
** The temperatures quoted are to be used as a guide
only and are subject to change based on the factors
such as ambient temperature, goods being stored,
power supply, and access to compartments etc.
Temperatures quoted are based on an ambient +32
degrees and an input voltage of 12.7V DC.
The temperature controls are set with a tolerance of
+/-3 degrees.
companionleisure.com.au
Freezer Section Fridge Section
Setting Min: +8º Setting Min: +2º
Setting 2: -0º Setting Max*: -5º
Setting 3: -12º
Setting 4: -15º
Setting Max*: -18º
COMPRESSOR ON
Compressor Status: when the LED is illuminated
the compressor is running.
