Removal and Replacement Procedures
Maintenance and Service Guide 5–39
2. Remove the RTC battery from the socket on the system board
(Figure 5-29).
✎
The notebook uses a BR1225 disk cell battery. The RTC battery
should be installed with the “+” facing up.
Figure 5-29. Removing the RTC Battery
Reverse the preceding procedure to install the RTC battery.
