Compaq 800 Series - No Video, Part 1

Troubleshooting
Maintenance and Service Guide 2–17
Flowchart 2.7—No Video, Part 2
Y
N
Continued from
Section 2.6,
No Video, Part 1.
Done
Adjust external
monitor display.
Video OK?
Adjust
display
brightness.
Video OK?
Video OK?
Done
Done
Check that notebook is properly
seated in docking station, for
bent pins on cable, and for
monitor connection.
Go to “A” in
Section 2.6,
No Video, Part 1.
Check brightness
of external
monitor.
Try another
external
monitor.
Internal
and external
video OK?
Go to Section 2.8,
Nonfunctioning
Docking Station.
Y
Y
Y
N
N
N
Remove
notebook from
docking station,
if connected.
