A Look at the Computer
Hardware Guide 2–15
8 Network cable (network models
only)**
Connects the computer to an
Ethernet network jack.
9 Bag containing spare pointing
stick caps (pointing stick
models only)
To replace a worn pointing stick
cap:
1. Turn off the computer.
2. Gently pull off the used rubber
pointing-stick cap.
3. Push the replacement cap into
place.
* The modem cable has a 6-pin RJ-11 connector at each end.
** The network cable has an 8-pin RJ-45 connector at each end.
Additional Standard Components (Continued)
Component Function
