Computer Upgrades and Add-ons
Hardware Guide 8–5
5. To add a memory board, insert the memory expansion board
into the empty memory expansion slot at a 45-degree
angle 1, then slide it gently into place until it is seated while
tilted. If a memory board is already installed, remove it. Refer
to “Removing a Memory Board” in this chapter.
✎
All memory expansion boards supported by the computer are
keyed (notched) to ensure correct positioning.
6. Push the memory expansion board down until the plastic
retention clips 2 snap into place.
7. Replace the memory expansion compartment cover and
install the screw.
