Compaq MV 740 User Manual

9
On-Screen Display Functions
Your On-Screen Display (OSD) menu accesses the following functions:
On-Screen Display Functions
On-Screen Display Function
Contrast
Adjusts display contrast
Brightness Adjusts display brightness
H. Position Shifts display right or left
H. Size Increases and decreases display width
V. Position Shifts display up or down
V. Size Increases and decreases display height
Pincushion Adjusts the concave and convex portion of the picture
Trapezoid Adjusts the top and bottom display widths to make them even
Pin. Balance Adjusts each side of Pincushion
Parallelogram Adjusts the tilt of the display sides to the left or right
Rotation Adjusts the tilt of the display
Degauss Demagnetizes screen to reduce color impurities
Color Temp Adjusts picture for more vibrant colors
Reset Resets monitor to factory default values
Exit Exits OSD menu

Compaq MV 740 Specifications

General

Brand	Compaq
Model	MV 740
Category	Monitor
Language	English
