Acceptable Signal Transmission Schemes
The following input sync information is for users who connect
this monitor to a non-Compaq computer. You may need to
provide your own cables or connectors to the computer. If you
are a nontechnical user and need more information than is
provided, contact a Compaq authorized dealer, reseller, or a
service provider.
Use the following signal transmission schemes when BNC
connectors are connected to the monitor.
Separate TTL Syncs, Separate Videos
Connect all five—Red, Green, Blue, Black and White—of the
interface connections.
Composite Sync, Separate Analog Videos
Connect the Red, Green, and Blue video inputs and the
horizontal sync input.
Sync Signal Definition:
Horizontal and vertical sync signals are
both provided through the horizontal input.
Connector Pin Assignments
Signal Cable
Connector Pin Signal
KEY 10
45
15 14
78
123
13 12 11
6
1
2
3
4
5
6
7
8
9
10
11
12
*
13
14
15
*
Red Video
Green Video
Blue Video
Open
Return
Red Gnd
Green Gnd
Blue Gnd
Reserved (No Pin)
Sync Return
Open
Bidirectional Data (SDA)
H-Sync/Composite Sync
V-Sync
Data Clock (SCL)
*
DDC Signals
