Operating the Monitor
Front Control Panel
Icon Control Function
1
Light Sensor Automatically adjusts contrast and
brightness to an appropriate level. This
function is turned On and Off using the on-
screen display.
2
Contrast Dial Adjusts Contrast.
3
Brightness Dial Adjusts Brightness.
4
Select Button
1. Launches on-screen display.
2. Selects function adjustments.
3. Exits menus and on-screen display.
5
-
Minus Button Selects or adjusts the functions.
6
+
Plus Button Selects or adjusts the functions.
7
Power Switch Turns the monitor on and off.
8
Power LED 1. Green indicates monitor is turned on.
2. Yellow indicates suspend mode.
3. Amber indicates sleep mode.
