— 41 —
The components identified by shading
and mark
are critical for safety.
Replace only with part number specified.
Note: Note:
The components identified by in this manual have been
carefully factory-selected for each set in order to satisfy
regulations regarding x-ray radiation. Should replacement
be required, replace only with the value originally used.
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
P900
R917 1-249-385-11 CARBON 2.2 5% 1/4W F
R918 1-214-964-00 METAL 1M 1% 1/4W
R919 1-216-073-00 RES,CHIP 10K 5% 1/10W
R920 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R921 1-216-049-91 RES,CHIP 1K 5% 1/10W
R923 1-215-469-00 METAL 100K 1% 1/4W
R924 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R925 1-218-762-11 METAL CHIP 270K 0.50% 1/10W
R926 1-216-073-00 RES,CHIP 10K 5% 1/10W
R927 1-220-823-91 CARBON 6.8K 5% 1/2W
R928 1-220-825-11 CARBON 330K 5% 1/2W
R929 1-216-089-91 RES,CHIP 47K 5% 1/10W
R930 1-219-748-11 CARBON 4.7K 5% 1/2W
R931 1-219-748-11 CARBON 4.7K 5% 1/2W
R932 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R933 1-216-666-11 METAL CHIP 4.3K 0.50% 1/10W
R934 1-249-377-11 CARBON 0.47 5% 1/4W F
R1001 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R1003 1-216-025-91 RES,CHIP 100 5% 1/10W
R1004 1-216-033-00 RES,CHIP 220 5% 1/10W
R1005 1-247-815-91 CARBON 220 5% 1/4W
R1006 1-216-033-00 RES,CHIP 220 5% 1/10W
R1010 1-216-033-00 RES,CHIP 220 5% 1/10W
R1011 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1012 1-216-017-91 RES,CHIP 47 5% 1/10W
R1013 1-216-017-91 RES,CHIP 47 5% 1/10W
R1014 1-216-025-91 RES,CHIP 100 5% 1/10W
R1015 1-216-033-00 RES,CHIP 220 5% 1/10W
R1016 1-216-033-00 RES,CHIP 220 5% 1/10W
R1017 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1018 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1019 1-216-017-91 RES,CHIP 47 5% 1/10W
R1020 1-216-017-91 RES,CHIP 47 5% 1/10W
R1021 1-216-025-91 RES,CHIP 100 5% 1/10W
R1022 1-216-025-91 RES,CHIP 100 5% 1/10W
R1039 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1046 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1047 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1048 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1049 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1050 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1051 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1065 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1070 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1072 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1073 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1074 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1083 1-216-025-91 RES,CHIP 100 5% 1/10W
R1084 1-216-041-00 RES,CHIP 470 5% 1/10W
R1085 1-216-025-91 RES,CHIP 100 5% 1/10W
R1086 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1092 1-216-033-00 RES,CHIP 220 5% 1/10W
R1093 1-216-033-00 RES,CHIP 220 5% 1/10W
R1094 1-216-113-00 RES,CHIP 470K 5% 1/10W
R1095 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1096 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1097 1-216-077-91 RES,CHIP 15K 5% 1/10W
R1098 1-216-077-91 RES,CHIP 15K 5% 1/10W
R1099 1-216-033-00 RES,CHIP 220 5% 1/10W
R1104 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
VARIABLE RESISTOR
RV901 1-241-767-21 RES, ADJ, CERMET 100K
3-710-578-01 COVER, VOLUME, 6 MOLD
RELAY
RY601 1-755-067-21 RELAY, AC POWER
RY602 1-755-318-11 RELAY, POWER
SWITCH
S602 1-771-757-11 SWITCH, PUSH (1 KEY)
SPARK GAP
SG901 1-517-499-21 GAP, SPARK
SG902 1-519-422-11 GAP, SPARK
SG903 1-519-422-11 GAP, SPARK
TRANSFORMER
T501 1-433-628-11 TRANSFORMER, FERRITE (HDT)
T502 1-411-594-41 INDUCTOR 5mH
T503 1-435-140-11 TRANSFORMER, FERRITE (LCT)
T504 1-431-413-21 TRANSFORMER, FERRITE (HST)
T602 1-435-141-11 TRANSFORMER, CONVERTER (SRT)
T701 1-435-129-11 TRANSFORMER, FERRITE (DFT)
T901 1-453-317-11 FBT ASSY NX-4700//X4E4
T902 1-411-567-31 INDUCTOR 500µH
THERMISTOR
TH600 1-809-260-11 THERMISTOR, POWER
TH601 1-803-540-11 THERMISTOR
