— 42 —
REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Note: Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
The components identified by shading
and mark
are critical for safety. Replace
only with part number specified.
P900
VARISTOR
VA601 1-801-073-31 VARISTOR TNR14V471K660
CRYSTAL
X1001 1-567-890-11 VIBRATOR, CRYSTAL
* A-1372-725-A H BOARD, COMPLETE
4-071-071-01 HOLDER, LED
CAPACITOR
C2002 1-126-786-11 ELECT 47µF 20% 16V
CONNECTOR
CN2001 * 1-564-523-11 PLUG, CONNECTOR 8P
DIODE
D2001 8-719-025-62 DIODE SML1216W
D2004 8-719-070-11 DIODE NNCD5.6A-T1
D2005 8-719-970-83 DIODE HSS82
D2006 8-719-970-83 DIODE HSS82
D2007 8-719-970-83 DIODE HSS82
D2008 8-719-970-83 DIODE HSS82
FERRITE BEAD
FB2001 1-412-911-11 FERRITE 0µH
FB2002 1-412-911-11 FERRITE 0µH
FB2003 1-412-911-11 FERRITE 0µH
FB2004 1-412-911-11 FERRITE 0µH
FB2005 1-412-911-11 FERRITE 0µH
TRANSISTOR
Q2001 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q2002 8-729-119-76 TRANSISTOR 2SA1175-HFE
RESISTOR
R2001 1-249-422-11 CARBON 2.7K 5% 1/4W
R2002 1-249-429-11 CARBON 10K 5% 1/4W
R2003 1-249-429-11 CARBON 10K 5% 1/4W
R2004 1-215-411-00 METAL 390 1% 1/4W
R2005 1-215-417-00 METAL 680 1% 1/4W
D N
R2006 1-249-411-11 CARBON 330 5% 1/4W
R2007 1-249-413-11 CARBON 470 5% 1/4W
R2008 1-249-415-11 CARBON 680 5% 1/4W
R2009 1-249-417-11 CARBON 1K 5% 1/4W
R2011 1-249-421-11 CARBON 2.2K 5% 1/4W
R2012 1-249-429-11 CARBON 10K 5% 1/4W
R2013 1-249-425-11 CARBON 4.7K 5% 1/4W
SWITCH
S2001 1-571-427-11 SWITCH, SLIDE
S2002 1-762-196-21 SWITCH, TACTILE
S2003 1-762-196-21 SWITCH, TACTILE
S2004 1-762-196-21 SWITCH, TACTILE
S2005 1-762-196-21 SWITCH, TACTILE
S2006 1-762-196-21 SWITCH, TACTILE
S2007 1-762-196-21 SWITCH, TACTILE
S2008 1-762-196-21 SWITCH, TACTILE
N
* A-1390-957-A N BOARD, COMPLETE
CAPACITOR
C801 1-113-340-11 ELECT 47µF 20% 25V
C803 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C809 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C810 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C811 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C812 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C813 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C814 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C817 1-119-941-91 ELECT 470µF 20% 6.3V
C818 1-113-340-11 ELECT 47µF 20% 25V
C819 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C820 1-119-941-91 ELECT 470µF 20% 6.3V
C821 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C822 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C823 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C824 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C825 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C826 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C827 1-119-941-91 ELECT 470µF 20% 6.3V
C828 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C829 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C830 1-113-340-11 ELECT 47µF 20% 25V
C832 1-131-722-91 ELECT 100µF 20% 6.3V
C833 1-163-038-91 CERAMIC CHIP 0.1µF 25V
