REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
Note:
Les composants identifies per un trame et une marque
sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
P900
Note:
The components identified by shading
and mark
are critical for safety. Replace
only with part number specified.
N
C835 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C837 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C838 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C839 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C840 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C841 1-163-023-00 CERAMIC CHIP 0.015µF 10% 50V
CONNECTOR
CN801 1-793-585-11 PIN, CONNECTOR (PC BOARD) 14P
CN802 1-793-586-11 PIN, CONNECTOR (PC BOARD) 14P
DIODE
D802 8-719-049-09 DIODE 1SS367-T3SONY
FERRITE BEAD
FB801 1-543-960-22 FERRITE 0µH
FB802 1-216-295-91 SHORT
FB809 1-543-963-22 FERRITE 0µH
FB810 1-543-963-22 FERRITE 0µH
IC
IC801 8-759-589-56 IC CXD9517Q
IC802 8-759-569-45 IC LD1117S33TR
IC803 8-759-502-82 IC LM324M-FL63
CHIP CONDUCTOR
JR801 1-216-295-91 SHORT
JR802 1-216-295-91 SHORT
TRANSISTOR
Q801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q804 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q805 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
RESISTOR
R801 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R802 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R803 1-216-033-00 RES,CHIP 220 5% 1/10W
R804 1-216-033-00 RES,CHIP 220 5% 1/10W
R805 1-216-033-00 RES,CHIP 220 5% 1/10W
R806 1-216-033-00 RES,CHIP 220 5% 1/10W
R807 1-216-033-00 RES,CHIP 220 5% 1/10W
R808 1-216-033-00 RES,CHIP 220 5% 1/10W
R809 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R810 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R811 1-240-983-91 METAL CHIP 1.5K 5% 1/10W
R812 1-216-049-91 RES,CHIP 1K 5% 1/10W
R813 1-216-049-91 RES,CHIP 1K 5% 1/10W
R814 1-216-031-00 RES,CHIP 180 5% 1/10W
R815 1-216-073-00 RES,CHIP 10K 5% 1/10W
R816 1-218-768-11 METAL CHIP 470K 0.50% 1/10W
R818 1-216-049-91 RES,CHIP 1K 5% 1/10W
R819 1-216-049-91 RES,CHIP 1K 5% 1/10W
R820 1-216-049-91 RES,CHIP 1K 5% 1/10W
R821 1-216-049-91 RES,CHIP 1K 5% 1/10W
R822 1-216-049-91 RES,CHIP 1K 5% 1/10W
R823 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R824 1-216-073-00 RES,CHIP 10K 5% 1/10W
R825 1-216-671-11 METAL 6.8K 0.50% 1/10W
R826 1-216-671-11 METAL CHIP 6.8K 0.50% 1/10W
R827 1-216-073-00 RES,CHIP 10K 5% 1/10W
R828 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R829 1-216-049-91 RES,CHIP 1K 5% 1/10W
R830 1-216-049-91 RES,CHIP 1K 5% 1/10W
R831 1-216-033-00 RES,CHIP 220 5% 1/10W
R832 1-216-025-91 RES,CHIP 100 5% 1/10W
R833 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R834 1-216-647-11 METAL CHIP 680 0.50% 1/10W
R835 1-216-089-91 RES,CHIP 47K 5% 1/10W
R836 1-216-049-91 RES,CHIP 1K 5% 1/10W
R837 1-216-648-11 METAL CHIP 750 0.50% 1/10W
R838 1-216-041-00 RES,CHIP 470 5% 1/10W
R839 1-216-117-00 RES,CHIP 680K 5% 1/10W
R840 1-216-650-11 METAL CHIP 910 0.50% 1/10W
R841 1-216-089-91 RES,CHIP 47K 5% 1/10W
R842 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R843 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R844 1-240-965-91 METAL CHIP 47 5% 1/10W
R846 1-216-025-91 RES,CHIP 100 5% 1/10W
R847 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R851 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R852 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R853 1-240-981-91 METAL CHIP 1K 5% 1/10W
R855 1-216-105-91 RES,CHIP 220K 5% 1/10W
R856 1-216-073-00 RES,CHIP 10K 5% 1/10W
R857 1-216-049-91 RES,CHIP 1K 5% 1/10W
R858 1-216-073-00 RES,CHIP 10K 5% 1/10W
R859 1-216-025-91 RES,CHIP 100 5% 1/10W
R860 1-216-025-91 RES,CHIP 100 5% 1/10W
R863 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R864 1-216-025-91 RES,CHIP 100 5% 1/10W
R866 1-216-049-91 RES,CHIP 1K 5% 1/10W
