REMOVAL & REPLACEMENT
Mass Storage Devices
Removing the Drive Cage Assembly, continued
Removal
6
Lift the (1) left side of the
Plastic Drive Cover and (2)
pull away from the drive cage
to remove the Plastic Drive
Cover from the drive cage.
Next Step
