* NOTE: This pin is used for self test detection; at PC side, this
pin must be connected to ground.
** NOTE: This monitor accepts +5V from the system graphic
card for asset management capability.
Signal Connector Pins
Pin Function
1 Red signal
2 Green signal
3 Blue signal
4 Ground
5 NC (*NOTE)
6 Red return
7 Green return
8 Blue return
9 +5V (**NOTE)
10 Ground
11 Ground
12 SDA (DDC 2B)
13 Horizontal Synchronization
14 Vertical Synchronization & VCLK
15 SCL (DDC 2B)

Compaq S920 Specifications

General

Screen Size	19” (48 cm) visual diagonal Viewable screen size 18” (46 cm) Anti-Glare Coating
Dot Pitch	0.26 mm (Diagonal) 0.22 mm (Horizontal)
Display Area Default	262 x 350 (mm) typical
Full Scan (H x W)	276 x 368 (mm), depends on signal timing
Display Colors	Infinite
Max. Resolution	1600 Dots x 1200 Lines
Compatibility	All graphic modes with horizontal frequencies between 30 KHz to 96 KHz
Synchronization Horizontal:	30 to 96 KHz
Synchronization Vertical:	50 to 160 Hz
Max Pixel Clock	202 MHz Max.
Input Signal	Video RGB Analog Sync. TTL Separate
Signal Cable	15-pin D-sub connector
Power Input Voltage Frequency	European Models: 200 to 240V AC Other Models: 100 to 240V AC 50-60 Hz
Current Rating	2.0 Amps
Power Consumption	120 W (Max.)

Weight and Dimensions

Dimension (W x H x D)	452 x 459 x 468 mm (approximate) 17.8” x 18.1” x 18.4”
Weight	20 kg Max. 44 lb Max.
