Troubleshooting
If your monitor fails to operate functionally, it may be possible to
correct the problem by making simple checks as follows:
Refer to the operating instructions for your computer/video
adapter to ensure that you have the correct signal output source
for the monitor. Ensure that the video adapter is set correctly for
operation with this monitor.
If the above steps fail to correct the problem contact your
Compaq service provider.
* NOTE: You can easily distinguish if the problem is on the
monitor or on the computer by using the monitor’s built-in
selftest function. With the monitor power ON, disconnect the
signal cable from the monitor. If you see a “CHECK SIGNAL”
image on the screen, the monitor is functioning properly, and the
problem is with the computer or signal cable.
Problem Check & Adjust
Blank screen (*NOTE)
■ Monitor power switch, power
cord, signal cable, or
connector
■ PC power switch
■ Brightness & contrast controls
Display position off-center
■ Vertical centering & horizontal
phase controls
Display too small or too large
■ Vertical & horizontal size
controls
Display too bright or too dim
■ Brightness & contrast controls

Compaq S920 Specifications

General

Screen Size	19” (48 cm) visual diagonal Viewable screen size 18” (46 cm) Anti-Glare Coating
Dot Pitch	0.26 mm (Diagonal) 0.22 mm (Horizontal)
Display Area Default	262 x 350 (mm) typical
Full Scan (H x W)	276 x 368 (mm), depends on signal timing
Display Colors	Infinite
Max. Resolution	1600 Dots x 1200 Lines
Compatibility	All graphic modes with horizontal frequencies between 30 KHz to 96 KHz
Synchronization Horizontal:	30 to 96 KHz
Synchronization Vertical:	50 to 160 Hz
Max Pixel Clock	202 MHz Max.
Input Signal	Video RGB Analog Sync. TTL Separate
Signal Cable	15-pin D-sub connector
Power Input Voltage Frequency	European Models: 200 to 240V AC Other Models: 100 to 240V AC 50-60 Hz
Current Rating	2.0 Amps
Power Consumption	120 W (Max.)

Weight and Dimensions

Dimension (W x H x D)	452 x 459 x 468 mm (approximate) 17.8” x 18.1” x 18.4”
Weight	20 kg Max. 44 lb Max.
