WARNING: To reduce the risk of possible injury, do not attempt to lift the
monitor by yourself. This monitor weighs approximately 65 pounds and is
not intended to be placed on top of a computer. However, the Compaq
Deskpro and Compaq Workstation computers are capable of supporting a
monitor that weighs up to 100 lbs. If you are not using a Compaq Deskpro
or Workstation, place the monitor directly on a desktop or other sturdy
work surface.
2. Connect one end of the monitor signal cable 2 to the monitor,
and the other end to the 15-pin connector on the rear panel of the
computer and tighten the screws.
Be sure the signal cable aligns with the 15-pin connector. Do
not force the cable onto the connector or you may damage the
signal cable.
3. Connect the monitor power cord 1 to the rear panel of the
monitor, then plug the other end into an electrical outlet that is
easily accessible and close to the monitor.
